P650 Movable 4G Antenna








P650 Movable 4G Antenna

Alternate View of The P650 Movable 4G Antenna

Features and Benefits:

  • Robust Stainless Steel And Polycarbonate Construction.
  • Small 1/2" Stainless Steel Pipe easily installs with NO DRILLING Required.
  • High Gain Antenna Design
  • Single Wing Nut removes antenna to enable movement to new Locations.
  • LMR-100 Low Loss Feed Line for Reliable Operation
  • 316 Stainless Steel Military Grade Connector with Cap
  • 13 Foot 316 Stainless steel cable Included for reliable instrument placement.

$575.00

Add to Cart


Antenna Part NumberP-650
Frequency Range700-960 / 1710- 2700MHZ
Gain5.0 dBi
Maximum VSWR<=2.0:1
PolarizationVertical
Max Input Power30 Watts
Input Impedance50 Ohms
Weight474g
Mechanical size100mm x 120mm
Mount Style1/2" 316 SST Threaded Pipe
Antenna Feed Line4.25M LMR-100 Low Loss Cable
Antenna TerminationSMA 316 SST (Sealed)
Water ResistanceSubmersible
Operating Temperature-40C to +85C




H2S Telemetry
